Volkswagen Jetta / Passat 4-Button Proximity Flip Key – NBGFS93N – 315 MHz – Megamos AES

Volkswagen Jetta / Passat 4-Button Proximity Flip Key – NBGFS93N – 315 MHz – Megamos AES

Aftermarket replacement proximity flip key for select Volkswagen Jetta and Passat vehicles equipped with the NBGFS93N MQB Keyless-Go system.

This 4-button flip key operates at 315 MHz and features a Megamos AES / MQB48 transponder system. The remote provides Lock, Unlock, Trunk Release, and Panic functions while supporting compatible proximity / Keyless-Go vehicle applications. The Panic button is located on the side of the remote.

The integrated flip blade uses the HU66 profile. This key is intended specifically for compatible MQB vehicles equipped with proximity / Keyless-Go functionality and should not be confused with non-proximity NBGFS93N flip keys that use different OEM part numbers. Always verify the FCC ID, OEM part number, frequency, proximity configuration, transponder type, button layout, and blade profile before ordering, cutting, or programming.

Key Features

• FCC ID: NBGFS93N
• IC: 2694A-FS93N
• Frequency: 315 MHz
• Transponder Chip: Megamos AES / MQB48
• Button Count: 4
• Button Layout: 3 front + 1 side
• Button Functions: Lock / Unlock / Trunk Release / Panic
• Key Type: Remote Flip Key
• Keyless Go / Proximity: Yes
• Platform: Volkswagen MQB
• Keyway / Blade: HU66
• Integrated Flip Blade: Yes
• Battery: CR2032
• Manufacturer Type: Aftermarket
• Condition: New

Product Information

• Compatible Make: Volkswagen
• Application Type: Remote / Proximity / Immobilizer
• Platform: MQB
• Proximity System: Keyless Go / PROX
• Integrated Flip Blade: Yes
• Keyway / Blade Profile: HU66
• Transponder: Megamos AES / MQB48
• Power Source: Battery Powered
• Battery Size: CR2032
• Programming: Dealer / Locksmith Programming Required
• Remote Features: Keyless Entry, Proximity Entry, Power Lock, Trunk Release, Panic Mode
• OEM / Service Cross-Reference: 5K0837202BJ / 5K0837202BP

Vehicle Compatibility

Volkswagen

• Jetta: 2017–2018
• Passat: 2017–2018



Important: FCC ID NBGFS93N exists in both proximity and non-proximity Volkswagen MQB configurations. FCC ID alone is therefore not sufficient to determine compatibility. Verify the original OEM part number, proximity / Keyless-Go system, 315 MHz frequency, button configuration, HU66 blade, and MQB transponder type before ordering, cutting, or programming.

Programming & Compatibility

This proximity flip key requires professional programming to the vehicle's MQB immobilizer and Keyless-Go system before use.

Professional Volkswagen-compatible locksmith or dealer programming equipment is required. Both the immobilizer credential and remote/proximity functions must be correctly matched to the vehicle.
