Volkswagen Jetta / Passat / Tiguan 4-Button MQB Prox Flip Key – NBGFS93N – 315 MHz
Volkswagen Jetta / Passat / Tiguan 4-Button MQB Prox Flip Key – NBGFS93N – 315 MHz
SKU:PLS-RMT-VW56F
Volkswagen Jetta / Passat / Tiguan 4-Button MQB Prox Flip Key – NBGFS93N – 315 MHz
Aftermarket 4-button remote flip key for select Volkswagen Jetta, Passat, and Tiguan vehicles equipped with the MQB proximity (Keyless-Go) remote and immobilizer system.
This key carries FCC ID NBGFS93N, operates at 315 MHz using ASK modulation, and uses a Megamos AES (MQB) transponder. The 4-button configuration provides Lock, Unlock, Trunk Release, and Panic — with the Panic button located on the side of the housing. The integrated flip blade uses the HU66 profile.
This is the proximity / Keyless-Go version, corresponding to OEM part number 5K0837202BJ. Always verify the FCC ID, OEM part number, frequency, transponder type, button layout, blade profile, and vehicle application before ordering, cutting, or programming.
Key Features
- FCC ID:
NBGFS93N - IC:
2694A-FS93N - Frequency:
315 MHz - Modulation:
ASK - Transponder Chip:
Megamos AES (MQB) - Button Count:
4 - Button Layout:
3+1 - Button Functions:
Lock / Unlock / Trunk Release / Panic (side-mounted) - Key Type:
Remote Flip Key - Platform:
Volkswagen MQB - Keyless Go / Proximity:
Yes - Keyway / Blade:
HU66 - Integrated Flip Blade:
Yes - Battery:
CR2032 - Colour:
Black - Manufacturer Type:
Aftermarket - Condition:
New
Product Information
- Compatible Make:
Volkswagen - Application Type:
Remote / Proximity / Immobilizer - Platform:
MQB - Remote Type:
Proximity / Keyless-Go - FCC ID:
NBGFS93N - IC:
2694A-FS93N - Transponder:
Megamos AES (MQB) - Keyway / Blade Profile:
HU66 - Integrated Flip Blade:
Yes - Power Source:
Battery Powered - Battery Size:
CR2032 - Programming:
Dealer / Locksmith Programming Required - Remote Features:
Keyless Entry, Proximity Entry, Power Lock, Trunk Release, Panic Mode - Primary OEM Part Number:
5K0837202BJ - Additional Cross-Reference:
5K0837202BP
Vehicle Compatibility
Volkswagen
- Jetta:
2017–2018 - Passat:
2017–2018 - Tiguan:
2012–2018
Important: FCC ID NBGFS93N exists in two distinct versions that look identical and differ only by OEM part number. This item is the proximity / Keyless-Go version, part number 5K0837202BJ. The non-proximity version uses part numbers 5K0837202AD and 5K0837202EC and is not interchangeable. Matching appearance, FCC ID, or the 315 MHz frequency alone does not establish compatibility — confirm the part number printed on the original key.
Programming & Compatibility
This flip key requires programming to the vehicle's MQB immobilizer and proximity system before use.
Professional Volkswagen-compatible locksmith or dealer programming equipment is required.
In this aftermarket version the transponder chip and the remote board are separate components, so both must be programmed — unlike the OEM key, which has the chip integrated into the board.
The flip blade must also be cut to match the vehicle before mechanical use.
